Steve Flanges, a well-respected manufacturer and supplier located in Canberra, Australia, is renowned for providing top-notch Copper Nickel Blind Flanges that adhere to global standards for durability, corrosion resistance, and performance. These flanges are meticulously crafted from high-quality copper-nickel alloys, ensuring exceptional strength and reliability, particularly in marine and offshore settings. With cutting-edge manufacturing techniques and rigorous quality control, Steve Flanges produces flanges that boast impressive dimensional accuracy and leak-proof sealing capabilities. Their Copper Nickel Blind Flanges are perfect for applications that demand long-lasting, maintenance-free solutions, even in harsh environmental and pressure conditions.
Copper Nickel Blind Flanges are mainly made up of copper and nickel, with small amounts of iron and manganese added to boost mechanical strength and corrosion resistance. The most common grades are Cu-Ni 70/30 (70% copper, 30% nickel) and Cu-Ni 90/10 (90% copper, 10% nickel). These flanges excel in resisting seawater, brine, and various corrosive chemicals. They offer good tensile strength, ductility, and toughness, maintaining stability even under high temperatures and pressures. Their non-magnetic and anti-biofouling characteristics make them especially suitable for marine and industrial applications.
| Specification | ASTM B151 / ASME SB151 |
|---|---|
| Size Chart | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JIS90/10220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092 |
| Pressure Rating ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Pressure Calculation in DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Coating | Oil Black Paint, Anti-rust Paint, Zinc Plated, Yellow Transparent, Cold and Hot Dip Galvanized |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Production Technique | Forged, Heat treated and machined |
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine, Sand-blasting machine etc |
| Manufacturer of | ANSI DIN, GOST, JIS, UNI, BS, AS2129, AWWA, EN, SABS, NFE etc. B.S: BS4504 , BS3293, BS1560, BS10 DIN: DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638 ASTM B151 70/30 Copper Nickel Flanges |
| Grades | Copper Nickel 70/30, 90/10 |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Steve Flanges, a leading supplier in Canberra, Australia, offers an extensive selection of Copper Nickel Blind Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Copper-nickel blind flanges find widespread applications in marine and offshore use because they possess very high resistance to seawater corrosion and bio-odor They find application in the field of pharmaceuticals, desalination plants and power plants under normal den in the. Blind flanges prevent water from passing through when required by closing the pipe or container end. The copper-nickel alloy offers cracking, pitting and stress cracking resistance, making it ideal for high temperature and high pressure.
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Cupro Nickel 90/10 | 2.0872 | C70600 |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
| ASME/ANSI B 16.5 | Blind Flange |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| ASME/ANSI B 16.47 | Blind Flange [Series A & B],Welding Neck Flange |
| PRESSURE CLASS | 75, 150, 300, 400, 600, 900 |
| ASME/ANSI B 16.36 | Blind Flange |
| PRESSURE CLASS | 300, 400, 600, 900, 1500, 2500 |
| PRESSURE CLASS | PN 2.5 TO PN 40 |
| BS 4504[PART 1] | Hubbed Slip-On |
| PRESSURE CLASS | PN 2.5 TO PN 400 |
| BS 1560 BOSS | Hubbed Slip-On Hubbed Threaded |
| PRESSURE CLASS | 150, 300, 400, 600, 900, 1500, 2500 |
| BS10 | Plate Slip-On Flange, Slip-On Boss Flange |
| TABLE | D, E, F, H |
| DIN FLANGES | DIN 2527, 2566, 2573, 2576, 2641,2642, 2655, 2656, 2627, 2628, 2629, 2631, 2632, 2633, 2634, 2635, 2636, 2637,2638, 2673 |
| PRESSURE CLASS | PN 6 TO PN 100 |
Yes, we offer custom sizes for Copper Nickel Blind Flanges to meet specific project needs. Our team at Steve Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@steveflanges.com.
You’ll find Copper Nickel Blind Flanges widely used across industries like shipbuilding, offshore oil and gas, desalination, power generation, and chemical processing. They primarily serve to seal the ends of pipelines, valves, and pressure vessel openings, preventing flow and allowing for pressure testing or maintenance. These flanges are particularly well-suited for seawater cooling systems, condensers, and heat exchangers, where corrosion resistance and leak prevention are crucial. With their ability to provide secure, durable, and efficient sealing, Copper Nickel Blind Flanges are a dependable choice for critical applications in marine and industrial piping systems.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
