Steve Flanges is a reliable manufacturer and supplier of Carbon Steel A36 flanges based in Canberra, Australia. With years of industry experience under their belt, they focus on crafting top-notch flanges that adhere to strict engineering standards. Renowned for their precision, durability, and dependability, Steve Flanges caters to various sectors, including oil and gas, petrochemical, construction, and water treatment. By merging cutting-edge manufacturing techniques with rigorous quality control, they ensure that every Carbon Steel A36 flange meets exact specifications. Their dedication to excellence has made Steve Flanges the go-to choice for clients looking for sturdy and long-lasting flanges in Canberra and its surrounding areas.
Carbon Steel A36 Flanges are primarily composed of iron with a carbon content of 0.26% to 0.29%, along with small amounts of manganese, phosphorus, and sulfur. Their mechanical properties include a minimum yield strength of 250 MPa and tensile strength ranging from 400 to 550 MPa. The advantages of A36 flanges include excellent weldability, good machinability, and high strength, making them suitable for various applications. They are cost-effective and widely used in construction, structural projects, and industrial piping systems, ensuring reliability and performance in demanding environments.
| Standards | ANSI/ASME B16.5, EN Flanges, BS 10, B16.47 Series A & B, EN-1092, ASME Flanges, BS Flanges, B16.48, DIN, DIN Flanges, GOST Flanges, ANSI Flanges, BS4504. |
| Size | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Pressure Rating | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Production technique | Forged, Heat treated and machined |
|
Special design |
As per your drawing |
| AS, ANSI, BS, DIN and JIS | |
| 15 NB (1/2″) to 200 NB (8″) | |
| Equal and Reducing Configurations | |
| Connect Type/ Flange Face Type | Ring Type Joint (RTJ), Small Tongue, Raised Face (RF), Lap-Joint Face (LJF), Small Male-Female (SMF), Flat Face (FF), Large Tongue & Groove, Large Male-Female (LMF). |
| Largest Bore Diameter Sizes | NPS ≤ 10 |
| Minimum & Maximum Size | 1/2″ To 48″ |
| Origin | Indian / Japan / Korean / West Europe / USA |
| JIS Standard | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| A182 Flange EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
|
Test Certificates |
EN 10204/3.1B |
| Raw Materials Certificate | |
| 100% Radiography Test Report | |
| Third Party Inspection Report, etc. | |
| Application | Gas, Power, Chemical, Metallurgy, Petroleum, Shipbuilding, Construction etc. |
| Grade | C | Si | Mn | P | S | Mo | Ni | Cr | Cu | V |
| A36 | 0.25 max | 0.40 max | 0.80 – 1.20 | 0.040 max | 0.050 max | – | – | – | – | – |
| Grade | Yield Strength ReH N/mm2 | Tensile Strength Rm N/mm2 | Elongation ( A ) | Impact Test ( J ) |
| A36 | 250 min | 400 – 550 | 20% min | – |
The Carbon Steel A36 flanges produced by Steve Flanges are crafted from high-quality carbon steel, providing impressive mechanical properties like high tensile strength, toughness, and durability. These flanges are engineered to endure extreme pressure and temperature conditions, guaranteeing reliable performance in demanding industrial settings. Their carefully controlled composition and heat treatment processes boost ductility and enhance resistance to wear and corrosion. Each flange undergoes thorough inspection to meet international quality standards, giving clients dependable and safe components for a variety of piping systems and industrial projects.
Carbon Steel A36 Flanges are commonly used in a variety of industries due to their strength and durability. They play a crucial role in piping systems, connecting pipes, valves, pumps, and fittings for the transport of fluids and gases in oil and gas, water treatment, and chemical processing sectors. These flanges are also utilized in construction for structural support and in manufacturing for machinery assembly. Their versatility makes them ideal for high-pressure and high-temperature applications, ensuring reliable connections and efficient operation across diverse industrial environments.
These Carbon Steel A36 flanges find extensive use in pipelines, oil and gas installations, chemical plants, power generation, and water treatment facilities throughout Canberra, Australia. They play a crucial role in connecting pipes, valves, pumps, and other equipment in high-pressure and high-temperature systems, allowing for maintenance, inspection, and system expansion without interrupting operations. Trusted by engineers and contractors alike, the products from Steve Flanges ensure safe, efficient, and long-lasting fluid and gas flow, making them an essential component in various industrial applications.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
