Steve Flanges is a reliable manufacturer and supplier of **Alloy 20 Orifice Flanges** based in Canberra, Australia. They offer top-notch products that are crafted for precision and durability, specifically designed for measuring and controlling fluid flow. These flanges are built to deliver accurate pressure drop readings in pipelines, making them crucial for effective process monitoring and regulation. Renowned for their outstanding corrosion resistance, particularly in environments with sulfuric acid and chlorides, Alloy 20 Orifice Flanges promise a long service life and dependable performance. Steve Flanges provides these flanges in a variety of sizes and specifications, all adhering to international quality standards.
The makeup of **Alloy 20 Orifice Flanges** includes about 30–34% nickel, 19–21% chromium, 3–4% molybdenum, and 2–3% copper, along with iron and trace elements. This nickel–iron–chromium alloy is known for its excellent resistance to pitting, crevice corrosion, and intergranular attack. In terms of mechanical properties, Alloy 20 boasts a tensile strength ranging from 520 to 750 MPa and a yield strength between 205 and 450 MPa, along with good elongation and toughness. Its unique blend of corrosion resistance and strength guarantees reliable performance in challenging process environments.
Alloy 20 Orifice Flanges Specifications: ASTM B462/ ASME SB462
Alloy 20 Orifice Flanges Dimensions: ANSI/ASME B16.36, Series A & B, BS4504, BS 10, EN-1092, DIN, etc.
Alloy 20 Orifice Flanges Standard: ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Alloy 20 Orifice Flanges Size: 1/2″ (15 NB) to 48″ (1200NB)
Alloy 20 Orifice Flanges Class / Pressure : 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
Alloy 20 Orifice Flange Face Type : Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
Steve Flanges, a leading supplier in Canberra, Australia, offers an extensive selection of Alloy 20 Orifice Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
**Alloy 20 Orifice Flanges** find extensive use in various industries, including chemical processing, oil and gas, petrochemical, pharmaceutical, power generation, and marine sectors. They are particularly suited for applications where precise flow measurement is essential, such as in the control and monitoring of process fluids. Their remarkable resistance to sulfuric acid, phosphoric acid, and chloride stress corrosion makes them ideal for harsh environments. Plus, their sturdy design ensures they can handle high pressure while maintaining leak-free performance. Alloy 20 Orifice Flanges are the go-to choice for critical flow control systems that demand both durability and corrosion protection.
| Grade | DIN | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
Yes, we offer custom sizes for Alloy 20 Orifice Flanges to meet specific project needs. Our team at Steve Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@steveflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
